Hinge Bases / T-Shaped / Standard / Oil-Free(Lista de números de peça: página 2)

■W Fixed

Part Number				H 1mm Increment	W	A	F	B	S	T	d	Oil Free Bushing
Type	D	H7 Type D Tolerance	Oil Free Type D Tolerance (Reference)									d (I.D.)	L (Overall Length)
(H7) HKTB HKTM HKTS (Oil Free) HKTBM	2	+0.01 0	-	15~20	4	22	15	H+3	5	6	3.5	-	-
	3			15~25	6	25		H+5		9	4.5
	4	+0.012 0	+0.062 0		8		17					4	6
	5		+0.065 0	20~30		32	23	H+6		12		5	6
	6				10			H+8				6	8
	8	+0.015 0		25~35		38	27		10	16	5.5	8	8
	10		+0.068 0	30~40			28	H+10				10	8
	12	+0.018 0			12					19		12	10
	13		-			50	37					-	-
	14			35~45				H+12	15	22	6.5	-	-
	15				16							-	-
	16											-	-
	20	+0.021 0		40~50	20	65	49	H+14		25	9	-	-
	25				30			H+17		30		-	-

 For detailed dimensions of Hinge Pin, see P.1-908.

■ HGBTBM
  Oil Free Bushing

D	W	Oil Free Bushing
		d (I.D.)	L (Overall Length)
4	4	4	3
	5	4	4
	6	4	5
	8	4	6
5	5	5	4
	6	5	5
	8	5	6
	9	5	8
	10	5	8
6	6	6	5
	8	6	6
	9	6	8
	10	6	8
	12	6	10
8	8	8	6
	9	8	8
	10	8	8
	12	8	10
	14	8	12
	15	8	12
	16	8	15
10	10	10	8
	12	10	10
	14	10	12
	15	10	12
	16	10	15
	18	10	15
12	12	12	10
	14	12	12
	15	12	12
	16	12	15
	18	12	15
13	14	13	12
	15	13	12
	16	13	15
	18	13	15
	20	13	15
	22	13	20
	24	13	20
15	15	15	12
	16	15	15
	18	15	15
	20	15	15
	22	15	20
	24	15	20
16	16	16	15
	18	16	15
	20	16	15
	22	16	20
	24	16	20

■ W and H Configurable Type (For Oil Free Type, H dimension is fixed)

Part Number				H7 Type		Oil Free Type		A	F	B	S	T	d
Type	D	H7 Type D Tolerance	Oil Free Type D Tolerance (Reference)	W 1mm Increment	H 5mm Increment	W Selectable	H Fixed
(H7) HGBTB HGBTM HGBTS (Oil Free) HGBTBM	2	+0.01 0	-	3~5	15~20	-	-	22	15	H+3	5	6	3.5
	3			3~6	15~25			25		H+5		9	4.5
	4	+0.012 0	+0.062 0	4~8		4 5 6 8	20		17
	5		+0.065 0	5~10	20~30	5 6 8 9 10		32	23	H+6		12
	6			6~12		6 8 9 10 12				H+8
	8	+0.015 0		8~16	25~35	8 9 10 12 14 15 16	25	38	27		10	16	5.5
	10			10~18	30~40	10 12 14 15 16 18	30		28	H+10
	12	+0.018 0	+0.068 0	12~18		12 14 15 16 18						19
	13			13~24		14 15 16 18 20 22 24		50	37
	14		-	14~24	35~45	-	-			H+12	15	22	6.5
	15		+0.068 0	15~24		15 16 18 20 22 24	35
	16			16~24		16 18 20 22 24
	20	+0.021 0	-	20~30	40~50	-	-	65	49	H+14		25	9
	25			25~35						H+17		30

 For detailed dimensions of Hinge Pin, see P.1-908.
