  • Adjustment Pads / Nonslip Type(Lista de números de peça: página 2)

    Número da peça:

    Indefinido. 116 candidatos encontrados.
    Quantidade:

    Desenho de contorno e tabela de especificações

    Dimensional Drawing


    [ ! ] M is coarse.
    [!] Do not drag the product sideways while it is loaded. This may cause the rubber to fall off.
    [ ! ] Electrically Conductive Rubber Specific Volume Resistivity 102 to 104 Ω·cm
    [ ! ] Screw shaft turns independently of the base and tilts slightly.

    Product Specifications

    Main BodyType(1) Main Body(2) Rubber Part
    [M] Material[S] Surface Treatment[M]Material (Color)[ H ] Hardness
    Stainless SteelFJGNSEN 1.4301 Equiv.Electrolytic PolishingElastomer (Black)
    FJGMS
    (Rubber selection)
    Neoprene Rubber (Black)
    Non-Migration Chloroprene Rubber (Gray)
    Electrically Conductive Rubber (Black)
    Shore A70
    Steel TypeFJGNEN 1.0038 Equiv.Trivalent ChromateElastomer (Black)
    FJGM
    (Rubber selection)
    Neoprene Rubber (Black)
    Non-Migration Chloroprene Rubber (Gray)
    Electrically Conductive Rubber (Black)
    PVC (Dark Blue)
    Shore A70

    Specification Table

    Part NumberRubber Material
    FJGM16 − 75R
    Part NumberFJGMS·FJGMLD12EBHM
    (Coarse)
    Thread
    pitch
    Vertical
    Load Capacity (kN)
    Mass (g)
    TypeM-ARubber Material
    Stainless Steel
    FJGNS
    FJGMS

    (Rubber selection)


    Steel Type
    FJGN
    FJGM

    (Rubber selection)
    8-50R
    (Neoprene rubber, black)

    C
    (Non-migration Chloroprene Rubber, Gray)

    D
    (Electrically Conductive Rubber, Black)

    S
    (PVC, Dark Blue)
    70.5455.56.51513681.253.950
    8-100120.570
    10-75977817101.54.391
    10-100122103
    12-751067081023197121.754.9178
    12-100131196
    12-125156212
    12-150181231
    16-7511080101325248162.05.9301
    16-100135331
    16-130165370
    16-150185397
    16-180215436
    20-100138131630202.56.8473
    20-130168533
    20-150188576
    20-180218641
    [!] Rubber material for FJGN and FJGNS cannot be selected. (Elastomer is used) *PVC rubber applicable sizes

    Cautions / Prohibitions

    This may cause the rubber to fall off.Do not apply lateral force when a load is applied to the rubber part. (Please use casters, etc.)

    Lista de números de peça

    Número de itens

    Thread Material

    Thread Surface Treatment

    Body Material

    Main Body Surface Treatment

    Rubber Material

    Width D

    (mm)

    Allowable Load (Details)

    (kN)

    Screw Length A

    (mm)

    Main Body Height

    (mm)

    Thread Nominal M

    (mm)

    Properties

    RoHS?Quantidade mínima de encomenda
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    70
    4.9
    75
    23
    12
    Electrical Conductivity
    -
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Neoprene Rubber] Neoprene Rubber (Black)
    70
    4.9
    75
    23
    12
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Chloroprene Rubber] Non-Migration Chloroprene Rubber (Gray)
    70
    4.9
    100
    23
    12
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    70
    4.9
    100
    23
    12
    Electrical Conductivity
    -
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    70
    4.9
    100
    23
    12
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Chloroprene Rubber] Non-Migration Chloroprene Rubber (Gray)
    70
    4.9
    125
    23
    12
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    70
    4.9
    125
    23
    12
    Electrical Conductivity
    -
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    70
    4.9
    125
    23
    12
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Chloroprene Rubber] Non-Migration Chloroprene Rubber (Gray)
    70
    4.9
    150
    23
    12
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    70
    4.9
    150
    23
    12
    Electrical Conductivity
    -
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Neoprene Rubber] Neoprene Rubber (Black)
    70
    4.9
    150
    23
    12
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Chloroprene Rubber] Non-Migration Chloroprene Rubber (Gray)
    80
    5.9
    75
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    80
    5.9
    75
    25
    16
    Electrical Conductivity
    -
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Neoprene Rubber] Neoprene Rubber (Black)
    80
    5.9
    75
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Chloroprene Rubber] Non-Migration Chloroprene Rubber (Gray)
    80
    5.9
    100
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    80
    5.9
    100
    25
    16
    Electrical Conductivity
    -
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    80
    5.9
    100
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Chloroprene Rubber] Non-Migration Chloroprene Rubber (Gray)
    80
    5.9
    130
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    80
    5.9
    130
    25
    16
    Electrical Conductivity
    -
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    80
    5.9
    130
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Chloroprene Rubber] Non-Migration Chloroprene Rubber (Gray)
    80
    5.9
    150
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    80
    5.9
    150
    25
    16
    Electrical Conductivity
    -
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Neoprene Rubber] Neoprene Rubber (Black)
    80
    5.9
    150
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Chloroprene Rubber] Non-Migration Chloroprene Rubber (Gray)
    80
    5.9
    180
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    80
    5.9
    180
    25
    16
    Electrical Conductivity
    -
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Synthetic Rubber] Electrically Conductive Rubber (Black)
    80
    5.9
    180
    25
    16
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    45
    3.9
    50
    15
    8
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    45
    3.9
    100
    15
    8
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    45
    4.3
    75
    15
    10
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    45
    4.3
    100
    15
    10
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    70
    4.9
    75
    23
    12
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    70
    4.9
    100
    23
    12
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    70
    4.9
    125
    23
    12
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    70
    4.9
    150
    23
    12
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    80
    5.9
    75
    25
    16
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    80
    5.9
    100
    25
    16
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    80
    5.9
    130
    25
    16
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    80
    5.9
    150
    25
    16
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    80
    5.9
    180
    25
    16
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    80
    6.8
    100
    25
    20
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    80
    6.8
    130
    25
    20
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    80
    6.8
    150
    25
    20
    Standard
    10
    1 unidades
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Steel] EN 1.0038 Equiv.
    Trivalent Chromate
    [Elastomer] Elastomer
    80
    6.8
    180
    25
    20
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    45
    3.9
    50
    15
    8
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    45
    3.9
    100
    15
    8
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    45
    4.3
    75
    15
    10
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    45
    4.3
    100
    15
    10
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    70
    4.9
    75
    23
    12
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    70
    4.9
    100
    23
    12
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    70
    4.9
    125
    23
    12
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    70
    4.9
    150
    23
    12
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    80
    5.9
    75
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    80
    5.9
    100
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    80
    5.9
    130
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    80
    5.9
    150
    25
    16
    Standard
    10
    1 unidades
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Stainless Steel] EN 1.4301 Equiv.
    Electrolytic Polishing
    [Elastomer] Elastomer
    80
    5.9
    180
    25
    16
    Standard
    10
    1 unidades
    Preço unitário (excluindo IVA)(Preço unitário incluindo IVA)
    Data de envio standard
    12.59 €
    ( 14.98 € )
    5 dias úteis
    12.08 €
    ( 14.38 € )
    5 dias úteis
    13.10 €
    ( 15.59 € )
    5 dias úteis
    13.35 €
    ( 15.89 € )
    5 dias úteis
    12.84 €
    ( 15.28 € )
    5 dias úteis
    13.23 €
    ( 15.74 € )
    5 dias úteis
    13.47 €
    ( 16.03 € )
    5 dias úteis
    12.98 €
    ( 15.45 € )
    5 dias úteis
    17.13 €
    ( 20.38 € )
    5 dias úteis
    17.39 €
    ( 20.69 € )
    5 dias úteis
    16.87 €
    ( 20.08 € )
    5 dias úteis
    18.00 €
    ( 21.42 € )
    5 dias úteis
    18.26 €
    ( 21.73 € )
    5 dias úteis
    17.62 €
    ( 20.97 € )
    5 dias úteis
    18.00 €
    ( 21.42 € )
    5 dias úteis
    18.26 €
    ( 21.73 € )
    5 dias úteis
    17.76 €
    ( 21.13 € )
    5 dias úteis
    18.63 €
    ( 22.17 € )
    5 dias úteis
    18.90 €
    ( 22.49 € )
    5 dias úteis
    18.40 €
    ( 21.90 € )
    5 dias úteis
    21.28 €
    ( 25.32 € )
    5 dias úteis
    21.54 €
    ( 25.63 € )
    5 dias úteis
    20.92 €
    ( 24.89 € )
    Item em stock: 1 dia útilDisponível para envio no próprio dia
    22.17 €
    ( 26.38 € )
    5 dias úteis
    22.41 €
    ( 26.67 € )
    5 dias úteis
    21.79 €
    ( 25.93 € )
    5 dias úteis
    4.03 €
    ( 4.80 € )
    Item em stock: 1 dia útilDisponível para envio no próprio dia
    6.80 €
    ( 8.09 € )
    5 dias úteis
    4.54 €
    ( 5.40 € )
    Item em stock: 1 dia útilDisponível para envio no próprio dia
    4.78 €
    ( 5.69 € )
    Item em stock: 1 dia útilDisponível para envio no próprio dia
    5.04 €
    ( 6.00 € )
    Item em stock: 1 dia útilDisponível para envio no próprio dia
    5.04 €
    ( 6.00 € )
    Item em stock: 1 dia útilDisponível para envio no próprio dia
    5.17 €
    ( 6.15 € )
    5 dias úteis
    6.30 €
    ( 7.50 € )
    5 dias úteis
    6.66 €
    ( 7.93 € )
    5 dias úteis
    6.66 €
    ( 7.93 € )
    Item em stock: 1 dia útilDisponível para envio no próprio dia
    6.93 €
    ( 8.25 € )
    5 dias úteis
    7.31 €
    ( 8.70 € )
    5 dias úteis
    7.56 €
    ( 9.00 € )
    Item em stock: 1 dia útilDisponível para envio no próprio dia
    7.81 €
    ( 9.29 € )
    5 dias úteis
    8.31 €
    ( 9.89 € )
    5 dias úteis
    8.57 €
    ( 10.20 € )
    Item em stock: 1 dia útilDisponível para envio no próprio dia
    8.95 €
    ( 10.65 € )
    5 dias úteis
    7.94 €
    ( 9.45 € )
    Item em stock: 1 dia útilDisponível para envio no próprio dia
    8.31 €
    ( 9.89 € )
    5 dias úteis
    11.71 €
    ( 13.93 € )
    5 dias úteis
    12.35 €
    ( 14.70 € )
    5 dias úteis
    13.23 €
    ( 15.74 € )
    5 dias úteis
    13.85 €
    ( 16.48 € )
    5 dias úteis
    14.11 €
    ( 16.79 € )
    5 dias úteis
    14.86 €
    ( 17.68 € )
    5 dias úteis
    18.90 €
    ( 22.49 € )
    5 dias úteis
    20.92 €
    ( 24.89 € )
    5 dias úteis
    21.40 €
    ( 25.47 € )
    5 dias úteis
    22.92 €
    ( 27.27 € )
    5 dias úteis
    23.93 €
    ( 28.48 € )
    5 dias úteis

    Informações detalhadas

    Informações básicas

    [Features] The rubber of the pad part grips the floor surface. [Material of threaded part] Stainless steel / steel
