Felt plates / PES, PA, WO (PET) / adhesive layer

CatálogoP. 2-447

Número da peça:

Indefinido. 26 candidatos encontrados.

Desenho de contorno e tabela de especificações
Lista de números de peça
Informações detalhadas
Catálogo

Desenho de contorno e tabela de especificações

Dimensional Drawing

Felt Sheets: Related Image

[ ! ]A ≥ B

■Dimensional tolerance of A and B

20 to 200	210 to 400	410 to 1000
±2	±4	±6

No Adhesive	Adhesive	[M] Material	Density (g/㎤)	Color	Allowable Temperature
FELP	FELPA	Polyester Felt	0.2 (0.18 when T = 5.5)	White	0 to 120°C
FELPET	FELPETA	Polyester Felt (with Binder)	0.32	Gray	0 to 80°C
FELH	FELHA	Polyamide Felt	0.2 (0.27 when T = 1)	White	−50 to 250°C
FELWL	FELWLA	Sheep Wool Felt (Including rayon and PET)	0.25	Ivory	−10 to 60°C
FELW	FELWA	Sheep Wool Felt	0.6	Ivory	−10 to 60°C

[ ! ] Adhesive thickness is 0.06 to 0.10 mm.

Specification Table

Part Number	—	A	—	B
FELP3	—	500	—	350

Part Number	T Selection	10 mm Increments
		A	B
FELP FELPA	1 3 5.5	20 to 1000	20 to 950
FELPET FELPETA	5	20 to 500	20 to 500
FELH FELHA	1 4 6
FELWL FELWLA	2 5 10
FELW FELWA

Lista de números de peça

Número de itens

Número da peça

With or w/o Adhesive

Thickness T

(mm)

Width A

(mm)

Length B

(mm)

Specifications

RoHS?

Quantidade mínima de encomenda

No Adhesive	1	20 - 500	20 - 500	Polyamide Felt	10	1 unidades
No Adhesive	4	20 - 500	20 - 500	Polyamide Felt	10	1 unidades
No Adhesive	6	20 - 500	20 - 500	Polyamide Felt	10	1 unidades
Adhesive	1	20 - 500	20 - 500	Polyamide Felt	10	1 unidades
Adhesive	4	20 - 500	20 - 500	Polyamide Felt	10	1 unidades
Adhesive	6	20 - 500	20 - 500	Polyamide Felt	10	1 unidades
No Adhesive	1	20 - 1000	20 - 950	Polyester Felt	10	1 unidades
No Adhesive	3	20 - 1000	20 - 950	Polyester Felt	10	1 unidades
No Adhesive	5.5	20 - 1000	20 - 950	Polyester Felt	10	1 unidades
Adhesive	1	20 - 1000	20 - 950	Polyester Felt	10	1 unidades
Adhesive	3	20 - 1000	20 - 950	Polyester Felt	10	1 unidades
Adhesive	5.5	20 - 1000	20 - 950	Polyester Felt	10	1 unidades
No Adhesive	5	20 - 500	20 - 500	Polyester Felt (with Binder)	10	1 unidades
Adhesive	5	20 - 500	20 - 500	Polyester Felt (with Binder)	10	1 unidades
No Adhesive	2	20 - 500	20 - 500	Sheep Wool Felt	10	1 unidades
No Adhesive	5	20 - 500	20 - 500	Sheep Wool Felt	10	1 unidades
No Adhesive	10	20 - 500	20 - 500	Sheep Wool Felt	10	1 unidades
Adhesive	2	20 - 500	20 - 500	Sheep Wool Felt	10	1 unidades
Adhesive	5	20 - 500	20 - 500	Sheep Wool Felt	10	1 unidades
Adhesive	10	20 - 500	20 - 500	Sheep Wool Felt	10	1 unidades
No Adhesive	2	20 - 500	20 - 500	Sheep Wool Felt (Rayon, PET blended)	10	1 unidades
No Adhesive	5	20 - 500	20 - 500	Sheep Wool Felt (Rayon, PET blended)	10	1 unidades
No Adhesive	10	20 - 500	20 - 500	Sheep Wool Felt (Rayon, PET blended)	10	1 unidades
Adhesive	2	20 - 500	20 - 500	Sheep Wool Felt (Rayon, PET blended)	10	1 unidades
Adhesive	5	20 - 500	20 - 500	Sheep Wool Felt (Rayon, PET blended)	10	1 unidades
Adhesive	10	20 - 500	20 - 500	Sheep Wool Felt (Rayon, PET blended)	10	1 unidades

Preço unitário (excluindo IVA)(Preço unitário incluindo IVA)	Data de envio standard

- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis
- ( - )	7 dias úteis

Informações básicas

[Features] Suitable for lubricating films, airtight packaging material, abrasives, etc.

Informações técnicas

Contorno e especificações

General Information - Panels (polyurethane rubber, rubber, foam, felt)

Selection details of panels (polyurethane rubber, rubber, foam, felt)

- Material: polyurethane rubber (PU/PUR), heat-resistant polyurethane rubber, low-impact polyurethane rubber, abrasion-resistant polyurethane rubber, antistatic polyurethane, nitrile (NBR), chloroprene rubber (CR), polyethylene (EPDM), silicone (SI), fluorine (FPM), butyl rubber (IIR), natural rubber (NR), hard rubber, special synthetic rubber, polyurethane foam, head-insulating foam, polyethylene foam, low-rebound foam

- Thickness (mm): 0.5 to 50

- Width (mm): 3 to 500

- Length (mm): 10 to 2000

Description/Basics

Foam plates and rubber plates are provided for damping or for sound proofing. MISUMI offers these in various Shore hardening for a wide variety of tasks. Due to the variety of materials, different resistances to environmental influences are possible depending on the application. The foam plates reduce sound in machines and can reduce the sound emissions of a system. For more information on foam characteristics, follow this link.
Rubber plates or foam plates are also suitable in conveyor systems to absorb components to be transported at a dampened level or to protect them from damage as a lateral guide when the components bump into each other. Hard rubber panels or low-impact rubber or foam panels reduce the impact energy of the components. These minimize and lower the vibrations in an application.
In addition, MISUMI offers highly abrasion-resistant polyurethane (Vulkollan), which has an abrasion resistance that is six times higher than with conventional polyurethane.
Ceramic polyurethane plates contain ceramic particles. After machining, these can have a smooth surface despite low Shore hardness.
The polyurethane rubber plates are also available antistatically. The specific resistance of antistatic polyurethane plates prevents static charging. This prevents any damage to electronic components.
For applications with higher temperatures, MISUMI offers heat-resistant polyurethane rubber, which can withstand a temperature range of up to approx. ~120°C (see the product specifications for exact information).
MISUMI also offers low-friction and anti-friction rubber plates. Low-friction rubber plates are often used in the gentle component guide for belt conveyors and roller conveyors.
Felt plates have the property of absorbing or dispensing oil and other liquids via the capillary effect. This property can be used to remove, for example, excess oil on a belt conveyor.

In addition, MISUMI offers rubber plates and foam plates that are self-adhesive for simplified assembly. Furthermore, you will find double-adhesive tape for attaching rubber plates and foam plates.

Additional properties on foam panels and rubber plates can be found in the Properties PDF.

MISUMI also offers these products in a round shape as discs and sleeves made of rubber, natural rubber, foam and felt.
