Vacuum Pad, Soft Bellows Type, VPA, Barb Fitting Type

Número da peça:

Indefinido. 10 candidatos encontrados.
Quantidade:

Informações do produto

Dimensions

Vacuum Pad, Sponge Small Type, VPMB, One Touch Fitting Type
Vacuum Pad, Sponge Small Type, VPMB, One Touch Fitting Type

Standard table

Model codePad O.D.
ød
Tube I.D.
øD
BL1L2Connection
config. code
VPA6LB[5]-6B[9]6444.11522.1-M4
VPA8LB[5]-6B[9]8
VPA10LB[5]-6B[9]1044.615.522.6
VPA15LB[5]-6B[9]1517.524.6
VPA20LB[5]-6B[9]20562028-M6

Units: mm

*[5]: Replaced with Pad rubber material code. Refer to the catalog for details.
*[9]: Replaced with "-S3" for -S3 spec. (Copper alloy free material for metal parts and FKM or HNBR for sealing parts).
*Pad material N and NE are not suitable for use under ozone environment.
*Tightening torque of a pad holder fixing bulkhead nut is as below.
▪Pad dia.: ø6~ø15 mm ▶ 2.5~3.5 N·m, ø20 mm ▶ 12~14 N·m

Lista de números de peça

Número de itens

Rubber Group Material

Color

Outer Diameter D

(φ)

Height L1

(mm)

Full length B

(mm)

Mount Connection Screw

Quantidade mínima de encomenda
[Nitrile Rubber] Nitrile Rubber
Black
6
15
44.1
M8
1 unidades
[Silicone Rubber] Silicone Rubber
[White] White
6
15
44.1
M8
1 unidades
[Nitrile Rubber] Nitrile Rubber
Black
8
15
44.1
M8
1 unidades
[Silicone Rubber] Silicone Rubber
[White] White
8
15
44.1
M8
1 unidades
[Nitrile Rubber] Nitrile Rubber
Black
10
15.5
44.6
M8
1 unidades
[Silicone Rubber] Silicone Rubber
[White] White
10
15.5
44.6
M8
1 unidades
[Nitrile Rubber] Nitrile Rubber
Black
15
17.5
46.6
M8
1 unidades
[Silicone Rubber] Silicone Rubber
[White] White
15
17.5
46.6
M8
1 unidades
[Nitrile Rubber] Nitrile Rubber
Black
20
20
56.2
M12
1 unidades
[Silicone Rubber] Silicone Rubber
[White] White
20
20
56.2
M12
1 unidades
Preço unitário (excluindo IVA)(Preço unitário incluindo IVA)
Data de envio standard
17.16 €
(
20.42 €
)
11 dias úteis
19.50 €
(
23.20 €
)
11 dias úteis
17.16 €
(
20.42 €
)
11 dias úteis
19.50 €
(
23.20 €
)
11 dias úteis
17.16 €
(
20.42 €
)
11 dias úteis
19.50 €
(
23.20 €
)
11 dias úteis
17.63 €
(
20.98 €
)
11 dias úteis
20.42 €
(
24.30 €
)
11 dias úteis
16.85 €
(
20.05 €
)
11 dias úteis
19.62 €
(
23.35 €
)
11 dias úteis

Informações detalhadas

Informações básicas

Excellent flexibility and ideal for adherence of paper, plastic molded articles, etc. *CAD data for this series is being revised. Data will be available as soon as modifications are complete.

[Features]
· Pad rubber is flexible enough to adhere to plastic molded parts without leaving significant residual traces.
· A wide range of pad sizes, pad materials, and holder shapes are available.
· Can reduce the size of holders (A and B types) for existing vacuum pads, making it possible to save space.
· The pad section can be changed without removing the holder from the equipment, as is conventionally done.
· Moreover, this product is also compatible with an optional fall prevention valve and pad direct attachment type filter.
· Pad holder (VPHD and VPHE types) with vacuum inlet on both sides
