Groove Type Connector Photo / Micro-Sensor (Modulated Light) [EE-SPX-W]

[Features]
· Photo micro / sensor with built-in amplifier with less susceptibility to disturbance from light.
· Modulated light type strong against disturbance light.
· Power supply voltage ranges from DC5 to 24V.
· Includes bright light indicator light that is easy to see.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Products homepage

Data to be displayed: 30; 45; 60

Part Number
EE-SPX302-W2A 1M
EE-SPX302-W2A 2M
EE-SPX404-W2A 1M
EE-SPX405-W2A 1M

Standard Unit Price	Minimum order quantity	Standard Shipping Days ?	Shape	Detection Distance (mm)	Head maximum width (mm)	Head maximum height (mm)	Head maximum, depth (mm)	Operating Mode	Standard Detected Subject (mm)	Cord/cable length (mm)
77.95 €	1	7 Days	F Type	3.6	13	15.5	21.2	ON when light is interrupted	1 × 0.5mm or more of opaque body	1000
65.60 €	1	7 Days	F Type	3.6	13	15.5	21.2	ON when light is interrupted	1 × 0.5mm or more of opaque body	2000
54.96 €	1	6 Days	R Type	3.6	13	15.5	21.2	Light Seen - ON	1 × 0.5mm or more of opaque body	1000
54.96 €	1	10 Days	L Type	5	27.2	6.35	15.5	Light Seen - ON	2 × 0.8mm or more of opaque body	1000

Basic information

Detection Method	Through Beam Type	Luminescence Method	Modulated light (infrared light)	Output Format	NPN voltage output
Connection Method	Integrated Cable Type	Indicator Light Mode	Illuminated light (red)	Slit hole/width(mm)	0.5
Cord/cable specification	Vinyl-insulated round cord φ3.5, 3-core	Groove depth(mm)	-	Protective Structure	IP50
Mounting format	-	Between amplifiers(mm)	-	Applicable Pipe(φ)	-
Details Type	-

Configure

4Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.

The part number is completed.

Basic Attributes

Shape
- L Type
- F Type
- R Type
Clear
Detection Distance(mm)
3.6

5
Clear
Head maximum width(mm)
13

27.2
Clear
Head maximum height(mm)
6.35

15.5
Clear
Head maximum, depth(mm)
15.5

21.2
Clear
Operating Mode
- Light Seen - ON
- ON when light is interrupted
Clear
Standard Detected Subject(mm)
- 1 × 0.5mm or more of opaque body
- 2 × 0.8mm or more of opaque body
Clear
Cord/cable length(mm)
- 1000
- 2000
Clear
Type
- EE-SPX-W
Clear
Filter by CAD data type
- 2D
Clear
