Linear ball bearings / double flat round flange / steel / LMYMH
- Stock
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| LMYMH6UU |
| LMYMH8UU |
| LMYMH10UU |
| LMYMH12UU |
| LMYMH13UU |
| LMYMH16UU |
| LMYMH20UU |
| LMYMH25UU |
| LMYMH30UU |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Shaft Diameter (mm) | Overall Length L (mm) | Outer Diameter D (mm) | Basic Load Rating Dynamic Rating (Detail) (N) | Basic Load Rating Static Rating (N) | Tolerance of Inscribed Circle (Minus Side) (mm) | Eccentricity (μm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
4.30 € | 1 |
Same day
Stock | 6 | 19 | 12 | 206 | 265 | -0.009 | 12 | ||
4.17 € | 1 | 5 Days | 8 | 24 | 15 | 274 | 392 | -0.009 | 12 | ||
6.50 € | 1 | 5 Days | 10 | 29 | 19 | 372 | 549 | -0.009 | 12 | ||
5.29 € | 1 | 5 Days | 12 | 30 | 21 | 510 | 784 | -0.009 | 12 | ||
8.25 € | 1 | 5 Days | 13 | 32 | 23 | 510 | 784 | -0.009 | 12 | ||
8.17 € | 1 | 5 Days | 16 | 37 | 28 | 774 | 1180 | -0.009 | 12 | ||
8.50 € | 1 | 5 Days | 20 | 42 | 32 | 882 | 1370 | -0.01 | 15 | ||
13.38 € | 1 | 5 Days | 25 | 59 | 40 | 980 | 1570 | -0.01 | 15 | ||
14.38 € | 1 | 5 Days | 30 | 64 | 45 | 1570 | 2740 | -0.01 | 15 |
Loading...
Basic information
| Type2 | Flange | Style | Standard | Flange Type | Standard Flange |
|---|---|---|---|---|---|
| Material of Outer Cylinder | Bearing Steel | Outer Cylinder Surface Treatment | No Surface Treatment | Motion | Linear Motion |
| Lubrication Type | N/A | The circulation type of balls | Single | Accuracy | Standard Grade |
| Type | Flanged End Face | Length | Standard | Flange Shape | Round-shaped, 2 Set Screw Flats |
| The material of a ball | Bearing Steel | Seal | Available | W/ or w/o metal retainer | NA |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Shaft Diameter(mm)
-
Overall Length L(mm)
-
Outer Diameter D(mm)
-
Eccentricity(μm)
-
Type
- LMYMH
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- Same day
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
