Male Branch Connector KGLU One-Touch Fitting

SMC One-Touch fitting.
[Features]
· Stainless steel specifications for use in corrosive environments.
· SUS303 is used for metal parts.
· Suitable for use in CRT production lines where contact with copper must be avoided, as well as cleaning of food processing machines where water or salt water splashes.
· Suitable for use inside clean rooms where discoloration of copper materials and dust caused by corrosion must be avoided.
[Applications]
· Use to branch line at right angles to female thread.

(i)Remark

Product images may be representative images. Refer to the catalog for shape details.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Save
Similar products
Product data
CAD data not available

Data to be displayed: 30; 45; 60

Part Number
KGLU04-01
KGLU04-01S
KGLU04-02
KGLU04-02S
KGLU04-M5
KGLU06-01
KGLU06-01S
KGLU06-02
KGLU06-03
KGLU06-03S
KGLU06-M5
KGLU08-01
KGLU08-01S
KGLU08-02
KGLU08-02S
KGLU08-03
KGLU08-03S
KGLU10-02
KGLU10-02S
KGLU10-03
KGLU10-03S
KGLU10-04
KGLU10-04S
KGLU12-02
KGLU12-03
KGLU12-03S
KGLU12-04
KGLU12-04S

Standard Unit Price	Minimum order quantity	Standard Shipping Days ?	Main Body Material	Application	Operating Temperature (°C)	Compatible Tube Outer Diameter 1 (mm)	Connection Type	Connection screw	Number of Connection Tubes (pc.)	Color	Specifications	Release button color	Custom-made specifications	Options
10.81 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	4	R	1/8	2	White	ISO Class：6	White	N/A	-
10.94 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant
11.73 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	4	R	1/4	2	White	ISO Class：6	White	N/A	-
11.89 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant
10.81 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	4	M	5×0.8	2	White	ISO Class：6	White	N/A	-
11.89 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	6	R	1/8	2	White	ISO Class：6	White	N/A	-
12.06 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant
12.27 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	6	R	1/4	2	White	ISO Class：6	White	N/A	-
12.81 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	6	R	3/8	2	White	ISO Class：6	White	N/A	-
12.92 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant
11.89 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	6	M	5×0.8	2	White	ISO Class：6	White	N/A	-
12.92 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	8	R	1/8	2	White	ISO Class：6	White	N/A	-
13.03 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant
12.92 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	8	R	1/4	2	White	ISO Class：6	White	N/A	-
13.03 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant
13.48 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	8	R	3/8	2	White	ISO Class：6	White	N/A	-
13.66 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant
17.35 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	10	R	1/4	2	White	ISO Class：6	White	N/A	-
17.47 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant
17.35 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	10	R	3/8	2	White	ISO Class：6	White	N/A	-
17.53 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant
17.81 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	10	R	1/2	2	White	ISO Class：6	White	N/A	-
17.98 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant
19.02 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	-	R	1/4	2	White	ISO Class：6	White	N/A	-
19.02 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	-	R	3/8	2	White	ISO Class：6	White	N/A	-
19.18 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant
19.02 €	2	26 Days	[PP Resin] PP	Standard/Mini	-	-	R	1/2	2	White	ISO Class：6	White	N/A	-
19.18 €	2	26 Days	[EN 1.4305 Equiv. , EN 1.4301 Equiv.] PBT+EN 1.4305 Equiv.	Clean circumstance / Foods・Drug-Related	-5～60	-	-	-	-	-	ISO class: 6	-	-	With sealant

Basic information

Type	Single-Action / Screw	Fitting Type	Screw Mount Branch	Applicable Fluid	Water / Air
Thread Material	EN 1.4305 Equiv.	Packing, Material of O-Ring	EPDM (Fluorine Coating)	Screw Mounting, Branch	Branch Elbow

Configure

28Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.

The part number is completed.

Basic Attributes

Main Body Material
- EN 1.4305 Equiv. , EN 1.4301 Equiv.
  - PBT+EN 1.4305 Equiv.
- PP Resin
  - PP
Clear
Application
- Standard/Mini
- Clean circumstance
- Foods・Drug-Related
Clear
Compatible Tube Outer Diameter 1(mm)
4

6

8

10
Clear
Connection Type
- M
- R
Clear
Connection screw
- 1/2
- 1/4
- 1/8
- 3/8
- 5×0.8
Clear
Number of Connection Tubes(pc.)
- 2
Clear
Color
- White
Clear
Specifications
- ISO Class：6
- ISO class: 6
Clear
Release button color
- White
Clear
Custom-made specifications
- N/A
Clear
Options
- With sealant
Clear
Type
- KGLU
Clear

Filter by standard shipping days

All

26 Days or Less
Reset

Optional Attributes

Product images may be representative images. Refer to the catalog for shape details.
The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
