VTT-LP - Knobs with solid section -with retaining chain technopolymer

VTT-LP - Knobs with solid section -with retaining chain technopolymer
  • Volume Discount

ELESA

ELESA

Three-lobe knob with solid section, with retaining chain.
Glass-fibre reinforced polyamide based technopolymer, elastic fork in acetal based technopolymer (POM).
Ball cable and coupling heads in acetal resin based technopolymer, NERINOX treated stainless steel ring with two coils.
Suitable where it is necessary to prevent the loss of the knob.

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.


Data to be displayed
30
45
60
  1. 1
Part Number
168116
168226
168346
168495
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
d l
(mm) 		Material D
(φ) 		L
(mm) 		d1 Diameter h High performing lines l2 R Type of assembly Sub execution Description

10.47 €

1 Available 4 Days M5-Stainless steel2520122510Inox1020Blind holeVTT-SST-LPVTT.25-SST-M5-LP

10.78 €

1 Available 4 Days M6-Stainless steel3223143010Inox11.521Blind holeVTT-SST-LPVTT.32-SST-M6-LP

11.86 €

1 Available 4 Days M8-Stainless steel4027164013Inox13.521.5Blind holeVTT-SST-LPVTT.40-SST-M8-LP

13.38 €

1 Available 4 Days M1040Stainless steel50301950-Inox1522.5Threaded screwVTT-SST-p-LPVTT.50-SST-p-M10x40-LP

Loading...

  1. 1

Configure

Clear all

4Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.
The part number is completed.

Basic Attributes

  • d

    • M5
    • M6
    • M8
    • M10

    Clear

  • l(mm)

    • 16
    • 20
    • 30
    • 40

    Clear

  • D(φ)

    • 25
    • 32
    • 40
    • 50

    Clear

  • L(mm)

    • 20
    • 23
    • 27
    • 30

    Clear

  • d1

    • 12
    • 14
    • 16
    • 19

    Clear

  • Diameter

    • 25
    • 30
    • 40
    • 50

    Clear

  • h

    • 10
    • 13
    • 17

    Clear

  • High performing lines

    • Inox

    Clear

  • l2

    • 10
    • 11.5
    • 13.5
    • 15

    Clear

  • R

    • 20
    • 21
    • 21.5
    • 22.5

    Clear

  • Type of assembly

    • Blind hole
    • Threaded screw

    Clear

  • Sub execution

    • VTT-B-LP
    • VTT-SST-LP
    • VTT-SST-p-LP
    • VTT-p-LP

    Clear

  • Type

    • 168

    Clear

  • Material

    • Stainless steel
    • Polyamide
      • Technopolymer

    Clear

  • Filter by CAD data type

    • 2D
    • 3D

    Clear
