Contact module with 1 contact element

Click on this image to zoom in.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Related to	Standard Unit Price	Minimum order quantity	Volume Discount	Standard Shipping Days ?	Dielectric strength (kV)	Durability	Electrical lifespan	Product size (depth) (mm)	Product size (height) (mm)	Recess depth (mm)	Switching voltage (V)	Min. temperature (°C)	Max. temperature (°C)	Contact type	IP rating	Type (misc.)	Connection (components)	Mounting type
Data sheet	5.59 €	1		3 Days	-	-	-	27.7	33.2	27.7	500	-25	+70	1 maker	IP40, IP20	-	Screws	Front panel fixed
Data sheet	6.28 €	1		3 Days	-	-	-	27.7	33.2	27.7	500	-25	+70	1 breaker	IP40, IP20	-	Screws	Front panel fixed
Data sheet	6.15 €	1		3 Days	-	-	-	27.7	36	27.7	500	-25	+70	1 maker	IP40, IP20	-	Spring-loaded contacts	Front panel fixed
Data sheet	6.15 €	1		3 Days	-	-	-	27.7	36	27.7	500	-25	+70	1 breaker	IP40, IP20	-	Spring-loaded contacts	Front panel fixed
Data sheet	7.27 €	1		3 Days	-	-	-	27.7	33.2	27.7	500	-25	+70	1 maker	IP40, IP20	-	Screws	Floor fixed
Data sheet	6.71 €	1		19 Days	-	-	-	27.7	33.2	27.7	500	-25	+70	1 breaker	IP40, IP20	-	Screws	Floor fixed
Data sheet	7.27 €	1		3 Days	-	-	-	27.7	36	27.7	500	-25	+70	1 maker	IP40, IP20	-	Spring-loaded contacts	Floor fixed
Data sheet	7.88 €	1	Available	3 Days	-	-	-	27.7	36	27.7	500	-25	+70	1 breaker	IP40, IP20	-	Spring-loaded contacts	Floor fixed
-	14.81 €	1	Available	14 Days	6	1000 0000	1000 0000	49.7	34	-	-	-	-	1 breaker	IP20, IP40	With 1 contact	Screws	Front panel fixed
-	12.67 €	1	Available	14 Days	6	1000 0000	1000 0000	27.7	36	-	-	-	-	1 breaker	IP20, IP40	With 1 contact	Spring-loaded connector	Front panel fixed

Product type	Contact module	Product size (width)(mm)	9.8	Switching current (max.)(A)	10

Configure

10Suggestion of an applicable part number.

Some specification is not specified yet.

The part number is completed.

Basic Attributes

Dielectric strength(kV)
- 6
Clear
Durability
- 1000 0000
Clear
Electrical lifespan
- 1000 0000
Clear
Product size (depth)(mm)
27.7

49.7
Clear
Product size (height)(mm)
33.2

34

36
Clear
Recess depth(mm)
27.7
Clear
Switching voltage(V)
500
Clear
Min. temperature(°C)
- -25
Clear
Max. temperature(°C)
+70
Clear
Contact type
- 1 breaker
- 1 maker
Clear
IP rating
IP20, IP40

IP40, IP20
Clear
Type (misc.)
With 1 contact
Clear
Connection (components)
- Screws
- Spring-loaded connector
- Spring-loaded contacts
Clear
Mounting type
- Floor fixed
- Front panel fixed
Clear
