Cable-Clips Self-Adhesive / Black, Ecru / Bundle diameter 4.8, 9.6, 15.7mm / Polyamide 6.6 / Adhesive surface 31.7 x 28.6
- Volume Discount
・Product type: Clip
・Material: Polyamide 6.6
・Fastening method: Self-adhesive
・Temperature range(mm): Adhesive surface 31.7 x 28.6
・Colour: Black, Ecru
・Bundle diameter(mm): 4.8, 9.6, 15.7
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 5430 |
| 5431-SW |
| 5432 |
| 5433-SW |
| 5436 |
| 5439-SW |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Bundle diameter (mm) | Bundle Ø (max.) (mm) | Bundle Ø range | Colour | Manufacturer part # | Max. temperature (°C) | Min. temperature (°C) | Product size (width) (mm) | Product size (length) (mm) | Type (manufacturer type) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
0.20 € | 1 | Available | 3 Days | 4.8 | 4 | 4 mm (max) | Ecru | 5430 | - | - | 19 | 19 | 5430 | |
0.28 € | 1 | Available | 3 Days | 4.8 | 5 | 5 mm (max) | Black | 5431-SW | 50 | 40 | 19 | 19 | 5431-SW | |
0.29 € | 1 | Available | 3 Days | 9.6 | 8 | 8 mm (max) | Ecru | 5432 | - | - | 26 | 26 | 5432 | |
0.20 € | 1 | Available | 3 Days | 9.6 | 8 | 8 mm (max) | Black | 5433-SW | - | - | 26 | 26 | 5433-SW | |
0.32 € | 1 | Available | 3 Days | 15.7 | 15 | 15 mm (max) | Ecru | 5436 | - | - | 26 | 26 | 5436 | |
0.25 € | 1 | Available | 3 Days | 15.7 | 15 | 15 mm (max) | Black | 5439-SW | - | - | 26 | 26 | 5439-SW |
Loading...
Basic information
| Fastening method | Self-adhesive | Halogen-free | No | Material | Polyamide 6.6 |
|---|---|---|---|---|---|
| Product type | Clip | Temperature range(mm) | Adhesive surface 31.7 x 28.6 |
Configure
Basic Attributes
-
Bundle diameter(mm)
-
Bundle Ø (max.)(mm)
-
Bundle Ø range
-
Colour
-
Manufacturer part #
-
Max. temperature(°C)
-
Min. temperature(°C)
-
Product size (width)(mm)
-
Product size (length)(mm)
-
Type (manufacturer type)
Filter by standard shipping days
-
- All
- 3 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
