Blade connector
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
3822.67
Basic information
| Colour | Metal | Connection angle(°) | 180 | Connection | - |
|---|---|---|---|---|---|
| Connector thickness(mm) | 0.8 | Connector width(mm) | 4.8 | Contact material | Brass tin plated |
| Cross section | - | Hole Ø(mm) | 4.3 | Insulation type | Not insulated |
| Manufacturer part # | 3822.67 | Material (details) | Bronze Ms | Product type | Blade connector |
| RoHS-compliant | Yes | Size | 4.8 x 0.8 mm | Support sleeve | No |
| Surface properties | Tin plated | Type (manufacturer type) | 3822.67 | Type (misc.) | 4.8 x 0.8 mm |
This page is Blade connector , part number 3822.67.
You can find the detail information about specifications and dimensions on part number 3822.67.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
