Valve Plug
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| E11651 |
| E11652 |
| E11991 |
| E11992 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Material Nut | Electrical Connection - Socket | Max. Current Load Total (A) | Special Feature | Dimensions (mm) | |
|---|---|---|---|---|---|---|---|---|---|
31.03 € | 1 | 4 Days | - | Connector: 1 x valve type A DIN, angled; Moulded body: PP / FPM | 5 | Free from silicone | 28.5 x 29.5 x 47 | ||
31.03 € | 1 | 4 Days | Brass, nickel-plated | Connector: 1 x valve type B DIN, angled; Moulded body: PP / FPM; Locking: brass, nickel-plated | - | Free from silicone; Halogen-free | 28.5 x 24 x 49 | ||
38.26 € | 1 | 4 Days | - | Connector: 1 x valve type A DIN, angled; Moulded body: PP / FPM | 5 | Free from silicone; Halogen-free | 28.5 x 29.5 x 47 | ||
38.26 € | 1 | 4 Days | Brass, nickel-plated | Connector: 1 x valve type B DIN, angled; Moulded body: PP / FPM; Locking: brass, nickel-plated | - | Free from silicone; Halogen-free | 28.5 x 24 x 49 |
Loading...
Basic information
| Protection | IP 67 | Materials | PP; FKM | Operating Voltage(V) | < 24 AC/DC |
|---|---|---|---|---|---|
| Ambient Temperature(°C) | -20-80 | Overvoltage Protection | Yes; (VDR) | Moulded-Body Material | PP / FPM |
| Display | Switching status: 1 x LED, yellow |
Configure
Basic Attributes
-
Material Nut
-
Electrical Connection - Socket
-
Max. Current Load Total(A)
-
Special Feature
-
Dimensions(mm)
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
