Aluminum Coating Straight Drill RGASD
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| RGASD1.6 |
| RGASD1.9 |
| RGASD1.92 |
| RGASD1.94 |
| RGASD3.05 |
| RGASD3.4 |
| RGASD3.26 |
| RGASD4.05 |
| RGASD5.02 |
| RGASD5.47 |
| RGASD6.2 |
| RGASD6.5 |
| RGASD6.9 |
| RGASD7.0 |
| RGASD7.5 |
| RGASD7.8 |
| RGASD8.3 |
| RGASD8.6 |
| RGASD8.8 |
| RGASD9.0 |
| RGASD12.0 |
| RGASD13.0 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Diameter Dc (mm) | Groove Length L (mm) | Overall Length L (mm) | |
|---|---|---|---|---|---|---|---|
7.07 € | 1 | 6 Days | 1.6 | 20 | 43 | ||
7.07 € | 1 | 6 Days | 1.9 | 22 | 46 | ||
8.40 € | 1 | 6 Days | 1.92 | 22 | 46 | ||
8.40 € | 1 | 6 Days | 1.94 | 22 | 46 | ||
12.49 € | 1 | 6 Days | 3.05 | 33 | 61 | ||
17.54 € | 1 | 6 Days | 3.4 | 39 | 70 | ||
12.49 € | 1 | 6 Days | 3.26 | 36 | 65 | ||
15.25 € | 1 | 6 Days | 4.05 | 43 | 75 | ||
21.99 € | 1 | 6 Days | 5.02 | 52 | 86 | ||
21.55 € | 1 | 6 Days | 5.47 | 57 | 93 | ||
22.10 € | 1 | 6 Days | 6.2 | 63 | 101 | ||
22.10 € | 1 | 6 Days | 6.5 | 63 | 101 | ||
25.73 € | 1 | 6 Days | 6.9 | 69 | 109 | ||
25.73 € | 1 | 6 Days | 7 | 69 | 109 | ||
26.07 € | 1 | 6 Days | 7.5 | 69 | 109 | ||
31.14 € | 1 | 6 Days | 7.8 | 75 | 117 | ||
33.02 € | 1 | 6 Days | 8.3 | 75 | 117 | ||
35.88 € | 1 | 6 Days | 8.6 | 81 | 125 | ||
35.55 € | 1 | 6 Days | 8.8 | 81 | 125 | ||
63.57 € | 1 | 6 Days | 9 | 81 | 125 | ||
59.21 € | 1 | 6 Days | 12 | 101 | 151 | ||
80.50 € | 1 | 6 Days | 13 | 101 | 151 |
Loading...
Basic information
| work material | Aluminum / Copper | Tool Material Type | High-speed steel | Shank Type | Straight Shank |
|---|---|---|---|---|---|
| Coating Y/N | Available | Coating Type | CrN | With/without Oil Hole | N/A |
| tip angle(Degree) | 135° | Torsional Angle(°) | 32～40° | Diameter tolerance(mm) | h8 |
| Coating Details | CrN Coating |
Configure
Basic Attributes
-
Diameter Dc(mm)
-
Groove Length L(mm)
-
Overall Length L(mm)
-
Type
- RGASD
Filter by standard shipping days
-
- All
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
