Shoulder Bolts / Reamer Bolts

At MISUMI you will find highly configurable shoulder bolts in many geometric designs that can be customized to your needs. Use our configurator to pre-select your individual shoulder bolt, reamer bolt, or stripper bolt. Do you need help? Here you will find useful tutorials for using our configurator.

MISUMI has a variety of configurable fitting shoulder bolts for sale. Made in steel and stainless steel, our shoulder bolts come in strength classes 8.8, 10.9, A2-50 (similar to DIN 923, DIN 7968 ISO 7379). Thread diameters range from M2.5 to M30 and shaft lengths from 2 to 180 mm. Shoulder bolts can be configured with hexagon socket, slotted, Phillips, or hexagon (external hex). The available surface treatments (burnished, nickel-plated, passivated) make the shoulder bolts resistant to a variety of environmental influences.

Shoulder bolts are construction elements intended for connecting and guiding parts to be joined. MISUMI has shoulder bolts with flat heads in various drive shapes, such as knurling bolts, and hex head and socket shoulder bolts. The tight tolerance shaft of the shoulder bolt can also be used for short strokes as a type of guide column. This is often used in die cutting. The precisely manufactured shaft of the shoulder bolt enables very precise positioning and centring of the components to be joined. Shoulder bolts are essential for connecting rod end bearingsand articulated arms. Due to their versatility, shoulder bolts are indispensable in various industries.

MISUMI offers you various helpful tools that can significantly shorten and simplify the design process. Here are some of the useful tools:
meviy	Rapid-Design	FRAMES	Tech-Blog
On-Demand manufacturing via CAD data upload	Add-on for SOLIDWORKS	Software for aluminum profile design	Interesting articles

Technical Standard

59 itens

* Informações sobre dias de expedição, custos de expedição e preços

Comparar especificações

Número de itens a exibir:Ordenar por:

Reamer bolts / hexagon socket / tolerance e9 / 10.9, A2-50

DESCONTO
Volume Discount
Order quantities extended (D-JIT)

MISUMI

Reamer bolts / hexagon socket / tolerance e9 / 10.9, A2-50

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	2.5 ～ 16	-	10 ～ 150	-	Stainless Steel ～ Steel	Not Provided / Electroless Nickel Plating	Hex Socket

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Screws with shoulder / hexagon socket / stainless steel, steel / tolerance h7

Volume Discount
Stock

MISUMI

Screws with shoulder / hexagon socket / stainless steel, steel / tolerance h7

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Low Head	RoHS compliant (10 substances)	3 ～ 6	Not Applicable	3 ～ 10	-	Stainless Steel ～ Steel	Not Provided / Black Oxide / Electroless Nickel Plating	Hex Socket

Preço regular (excluindo IVA):

3.51 €～

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Reamer bolts / hexagon socket / tolerance g6, h7 / 10.9, A2-50

DESCONTO
Volume Discount
Order quantities extended (D-JIT)

MISUMI

Reamer bolts / hexagon socket / tolerance g6, h7 / 10.9, A2-50

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	2.5 ～ 8	-	10 ～ 60	-	Stainless Steel ～ Steel	Not Provided	Hex Socket

Preço regular (excluindo IVA):

1.72 €～

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Reamer bolts / hexagon socket / length configurable / tolerance g6, h7 / 10.9, A2-50

MISUMI

Reamer bolts / hexagon socket / length configurable / tolerance g6, h7 / 10.9, A2-50

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	3 ～ 10	-	10 ～ 60	-	Stainless Steel ～ Steel	Not Provided	Hex Socket

Data de envio regular:

7 dias úteis

- DESCONTO
- Volume Discount
GANTER
Reamer bolts / hexagon socket / steel / ISO 7379
Shoulder screws ISO 7379 are cost-saving construction elements for a wide variety of different uses.The maximum tightening torque must not be defined by strength class 12.9, it is instead limited by the relatively small bearing points (shoulders) and by the recesses at the transition point from d1 to d2 and d1 to d3.Standard deviation:- no information about the concentricity 2 IT 13 and IT 10 2- the official ISO standard sheet has the following dimensions for d1 - d2: 6,5-M5 / 13-M10 / 25-M20- the dimensions 4-M3 and M4-M5 are not included in the official ISO standard sheet
Ler mais
Detailed Shape Environmentally Friendly Screw Nominal (M) Properties / applications Length L (mm)(mm) Length L (inch)(inch) Material Surface Treatment Mounting Hole Shape
- - - - - - - - -
Preço regular (excluindo IVA):
0.90 €～
Preço regular (excluindo IVA):
Preço especial
Data de envio regular:
Item em stock: 1 dia útil
Alguns artigos podem ser enviados no próprio dia
Configurar

Screws with shoulder / drive selectable / stainless steel, steel

MISUMI

Screws with shoulder / drive selectable / stainless steel, steel

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Low Head / Extra Low Head / Button Head Cap	-	3 ～ 10	-	-	-	Stainless Steel ～ Steel	Not Provided / Black Oxide / Electroless Nickel Plating	Hex Socket / Cross Recessed

Data de envio regular:

7 dias úteis

Shoulder screws similar to DIN ISO 7379 (K0705)

KIPP

Shoulder screws similar to DIN ISO 7379 (K0705)

[Specifications]・Thread (M): 3-16・Material: Steel, Stainless Steel・Surface finish body: bright, tempered[Features]・Suitable for a range of different applications・Simplify complicated constructions・Version: steel or stainless steel (A2)・Ground shaft・DIN ISO 7379

Ler mais

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
-	-	3 ～ 20	-	-	-	Stainless Steel ～ Steel	-	-

Preço regular (excluindo IVA):

0.61 €～

Data de envio regular:

4 dias úteis

- Volume Discount
MAEDLER
Socket Shoulder Screws Similar ISO 7379, Steel
Material: Steel strength 12.9, partially black oxide finish.Screws with precision fit cylinder for multiple usage.These screws have the usual differences to the norm ISO 7379, like it is common on the market.Note:These screws have the usual differences to the norm ISO 7379, like it is common on the market:- Ø 4 mm and Ø 5 mm are not included in the ISO.- Ø 6 mm instead of ISO Ø 6.5 mm.- Ø 12 mm instead of ISO Ø 13 mm.- Ø 24 mm instead of ISO Ø 25 mm.- Concentricity 2 IT 13 and 2 IT 10 may vary.- The stainless steel version is not included in the ISO. Due to thematerial, the strenght is lower.Fastening Torque:Because of the small contact areas and the recesses, the tightening torque is much smaller than the torque for a standard bolt with strength 12.9 of the same thread size. Also, the strength of the contact areas of the corresponding parts must be considered.* At screw 12.9, the height of head is 8 mm.
Ler mais
Detailed Shape Environmentally Friendly Screw Nominal (M) Properties / applications Length L (mm)(mm) Length L (inch)(inch) Material Surface Treatment Mounting Hole Shape
- - M 3 ～ M 20 - - - Steel Black Oxide -
Preço regular (excluindo IVA):
0.82 €～
Data de envio regular:
4 dias úteis
Configurar

Reamer bolts / hexagon socket / length configurable / tolerance selectable / 9.8, A2-50

MISUMI

Reamer bolts / hexagon socket / length configurable / tolerance selectable / 9.8, A2-50

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Low Head	-	2.5 ～ 8	-	10 ～ 60	-	Stainless Steel ～ Steel	Not Provided	Hex Socket

Data de envio regular:

7 dias úteis

Socket Shoulder Screws Similar ISO 7379, Stainless Steel

Volume Discount

MAEDLER

Socket Shoulder Screws Similar ISO 7379, Stainless Steel

Material: Stainless steel 1.4301 (AISI 304).Screws with precision fit cylinder for multiple usage.These screws have the usual differences to the norm ISO 7379, like it is common on the market.Note:These screws have the usual differences to the norm ISO 7379, like it is common on the market:- Ø 4 mm and Ø 5 mm are not included in the ISO.- Ø 6 mm instead of ISO Ø 6.5 mm.- Ø 12 mm instead of ISO Ø 13 mm.- Ø 24 mm instead of ISO Ø 25 mm.- Concentricity 2 IT 13 and 2 IT 10 may vary.- The stainless steel version is not included in the ISO. Due to thematerial, the strenght is lower.Fastening Torque:Because of the small contact areas and the recesses, the tightening torque is much smaller than the torque for a standard stainless steel bolt A2-70 of the same thread size. Also, the strength of the contact areas of the corresponding parts must be considered.

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
-	-	M 3 ～ M 12	-	-	-	Stainless Steel	Not Provided	-

Preço regular (excluindo IVA):

3.52 €～

Data de envio regular:

4 dias úteis

Reamer bolts / drive selectable / tolerance g6

DESCONTO
Volume Discount
Order quantities extended (D-JIT)

MISUMI

Reamer bolts / drive selectable / tolerance g6

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	5 ～ 16	-	23 ～ 58	-	Stainless Steel ～ Steel	Not Provided / Black Oxide	Hex Socket / Not Provided

Preço regular (excluindo IVA):

1.85 €～

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Reamer bolts / hexagon socket / tolerance selectable / 9.8, A2-50

DESCONTO
Volume Discount
Order quantities extended (D-JIT)
Stock

MISUMI

Reamer bolts / hexagon socket / tolerance selectable / 9.8, A2-50

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Low Head	-	2.5 ～ 8	-	10 ～ 40	-	Stainless Steel ～ Steel	Not Provided	Hex Socket

Preço regular (excluindo IVA):

8.23 €～

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Reamer bolts / hexagon socket / tolerance h8 / ISO 7379

DESCONTO
Volume Discount

REYHER

Reamer bolts / hexagon socket / tolerance h8 / ISO 7379

Fitting shoulder screws; Shoulder fitting screws; compare DIN 9841

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
-	-	5 ～ 16	-	10 ～ 100	-	Stainless Steel ～ Steel	-	Hex Socket

Preço regular (excluindo IVA):

3.40 €～

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Shoulder screws similar to ISO 7379 (07534)

NORELEM

Shoulder screws similar to ISO 7379 (07534)

· Suitable for a range of different applications· Simplify complicated constructions· Version: steel or stainless steel (A 2)· Ground shaft

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
-	-	3 ～ 20	-	13 ～ 142	-	Stainless Steel ～ Steel	-	Hex Socket

Preço regular (excluindo IVA):

1.01 €～

Data de envio regular:

4 dias úteis

Reamer bolts / drive selectable / length configurable / tolerance g6

MISUMI

Reamer bolts / drive selectable / length configurable / tolerance g6

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	5 ～ 16	-	20 ～ 58	-	Stainless Steel ～ Steel	Not Provided / Black Oxide	Hex Socket

Data de envio regular:

6 dias úteis

- DESCONTO
- Volume Discount
GANTER
Reamer bolts / hexagon socket / stainless steel / ISO 7379
Stainless Steel-Shoulder screws ISO 7379 are cost-saving construction elements for a wide variety of different uses.The maximum tightening torque is limited by the relatively small bearing points (shoulders) and by the recesses at the transition point from d1 to d2 and d1 to d3.Standard deviation:- no information about the concentricity 2 IT 13 and IT 10 2- the official ISO standard sheet has the following dimensions for d1 - d2: 6,5-M5 / 13-M10 / 25-M20- the dimensions 4-M3 and M4-M5 are not included in the official ISO standard sheet
Ler mais
Detailed Shape Environmentally Friendly Screw Nominal (M) Properties / applications Length L (mm)(mm) Length L (inch)(inch) Material Surface Treatment Mounting Hole Shape
- - - - - - - - -
Preço regular (excluindo IVA):
4.18 €～
Preço regular (excluindo IVA):
Preço especial
Data de envio regular:
Item em stock: 1 dia útil
Alguns artigos podem ser enviados no próprio dia
Configurar
- Volume Discount
GANTER
Captive hexagon socket screws / stainless steel / thin shank for loss prevention
[Specifications]・Material: NI. Stainless SteelStainless steel captive socket cap screws GN 912.2 can be used to prevent loss of the thumb screw, due to the d3 recessed portion of the stud. Thus the "captivity of the mounting element "according to the Machinery Directive 2006 / 42 / EG is given.
Ler mais
Detailed Shape Environmentally Friendly Screw Nominal (M) Properties / applications Length L (mm)(mm) Length L (inch)(inch) Material Surface Treatment Mounting Hole Shape
- - - - - - - - -
Preço regular (excluindo IVA):
3.02 €～
Data de envio regular:
7 dias úteis
Configurar

[Clean & Pack] Low Head Shoulder Screw

Volume Discount

MISUMI

[Clean & Pack] Low Head Shoulder Screw

Three types of cleaning methods are available: degreasing, precision cleaning, and electrolytic polishing + precision cleaning. They can be ordered from one piece with the standard part number.This eliminates the need for customer cleaning or outsourced cleaning, reducing the amount of time and effort required.■Part Number for Clean & Pack Products·Degreasing (Anti-rust single packing)　　　　: Part Number SL-□□·Precision cleaning (Degassing double packing)　　　　: Part Number SH-□□·Electrolytic polishing + precision cleaning (Degassing double packing): Part Number SHD-□□Product Part NumberCleaning MethodPackaging TypeEffects Compared to Uncleaned ProductEnvironment (Standard)Possible applicationsSL-□□DegreasingAnti-rust packingOil removalGeneral environmentRegular assembly processPost battery assembly processSH-□□Precision cleaningDegassing double packingOil removalDust removalClean environment (Class 10 to 1,000*)Battery assembly processLCD-related post assembly processIn-vehicle camera assembly processSHD-□□Electrolytic polishing + precision cleaningDegassing double packingOil removalDust removalOutgas reductionVacuum environmentClean environment (Class 10 to 1,000*)Pre-semiconductor processLiquid crystal deposition processPre-OLED process*US FED STD 209E, ISO 14644-1 ISO 4 to ISO 6 Equiv.■NotesCleaning also removes rust prevention oil, which may make the product more susceptible to rusting than an uncleaned product.Please be careful about the application location and storage environment.

Ler mais

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Low Head	RoHS compliant (10 substances)	2.5 ～ 8	Clean washing	10 ～ 60	-	Stainless Steel	Not Provided	Hex Socket

Data de envio regular:

7 dias úteis

Flat head screws / slotted / shank / DIN 923 /

Volume Discount

REYHER

Flat head screws / slotted / shank / DIN 923 /

Slotted machine screws; slotted cheese head shoulder screws

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
-	-	3 ～ 10	-	0 ～ 25	-	Stainless Steel ～ Steel	-	With Cross/Straight Slot

Preço regular (excluindo IVA):

0.24 €～

Data de envio regular:

3 dias úteis

Low Head Shoulder Bolt - High Strength Stainless Steel Tapped Type, Shaft Dia. Tolerance g6

Volume Discount

MISUMI

Low Head Shoulder Bolt - High Strength Stainless Steel Tapped Type, Shaft Dia. Tolerance g6

A low head shoulder bolt made of stainless steel with equal strength to EN 1.7220 Equiv. L dimension length is configurable as an alteration.Click [Here] for high strength stainless steel threaded type.

Ler mais

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Low Head	RoHS compliant (10 substances)	2.5 ～ 6	Not Applicable	10 ～ 80	-	Stainless Steel	Not Provided	Hex Socket

Data de envio regular:

5 dias úteis

Shoulder screws with hexagon head similar to DIN 609 (07535)

NORELEM

Shoulder screws with hexagon head similar to DIN 609 (07535)

· For securing the position of workpieces· Ground shaft

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
-	-	8 ～ 24	-	25 ～ 120	-	Steel	-	Not Provided

Preço regular (excluindo IVA):

1.42 €～

Data de envio regular:

4 dias úteis

Trunnion screw / slotted / DIN 927

DESCONTO
Volume Discount

REYHER

Trunnion screw / slotted / DIN 927

Full dog point screws; Slotted grub screws

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
-	-	3 ～ 8	-	3 ～ 16	-	Steel	-	With Cross/Straight Slot

Preço regular (excluindo IVA):

0.16 €～

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Reamer bolts / hexagon socket / tolerance e9 / STG

DESCONTO
Volume Discount

OHKITA

Reamer bolts / hexagon socket / tolerance e9 / STG

Screw part developed to allow movable parts to be retained in suspension.

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	4 ～ 12	-	7 ～ 18	-	Steel	Other Special Treatment	Hex Socket

Preço regular (excluindo IVA):

1.29 €～

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Reamer bolts / knurled head / tolerance e9

Volume Discount
Stock

MISUMI

Reamer bolts / knurled head / tolerance e9

[Features] Wiper pin for knob applications.

Ler mais

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Knurling	-	4 ～ 8	-	15 ～ 40	-	Steel	Black Oxide	Hex Socket

Preço regular (excluindo IVA):

3.33 €～

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Reamer bolts / hexagon socket / black oxided / 10.9 / ST

DESCONTO
Volume Discount

GOSHO WORKS

Reamer bolts / hexagon socket / black oxided / 10.9 / ST【1 a 30 unidades】

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	5 ～ 16	-	20 ～ 120	-	Steel	Black Oxide	Hex Socket

Preço regular (excluindo IVA):

2.33 €～

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

[New Product]Low Head Shoulder Bolt - High Strength Stainless Steel Type, Shaft Dia. Tolerance g6

Volume Discount

MISUMI

[New Product]Low Head Shoulder Bolt - High Strength Stainless Steel Type, Shaft Dia. Tolerance g6

A low head shoulder bolt made of stainless steel with equal strength to SCM435. L dimension length and F dimension thread length are configurable as alterations.

Ler mais

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Low Head	-	2.5 ～ 8	-	15 ～ 30	-	Stainless Steel	Not Provided	Hex Socket

Data de envio regular:

5 dias úteis

[Clean & Pack] Shoulder Screw - Dimension Selectable, Shaft Dia. Tolerance g6/h7

Volume Discount

MISUMI

[Clean & Pack] Shoulder Screw - Dimension Selectable, Shaft Dia. Tolerance g6/h7

Three types of cleaning methods are available: degreasing, precision cleaning, and electrolytic polishing + precision cleaning. They can be ordered from one piece with the standard part number.This eliminates the need for customer cleaning or outsourced cleaning, reducing the amount of time and effort required.■Part Number for Clean & Pack Products·Degreasing (Anti-rust single packing)　　　　: Part Number SL-□□·Precision cleaning (Degassing double packing)　　　　: Part Number SH-□□·Electrolytic polishing + precision cleaning (Degassing double packing): Part Number SHD-□□Product Part NumberCleaning MethodPackaging TypeEffects Compared to Uncleaned ProductEnvironment (Standard)Possible applicationsSL-□□DegreasingAnti-rust packingOil removalGeneral environmentRegular assembly processPost battery assembly processSH-□□Precision cleaningDegassing double packingOil removalDust removalClean environment (Class 10 to 1,000*)Battery assembly processLCD-related post assembly processIn-vehicle camera assembly processSHD-□□Electrolytic polishing + precision cleaningDegassing double packingOil removalDust removalOutgas reductionVacuum environmentClean environment (Class 10 to 1,000*)Pre-semiconductor processLiquid crystal deposition processPre-OLED process*US FED STD 209E, ISO 14644-1 ISO 4 to ISO 6 Equiv.■NotesCleaning also removes rust prevention oil, which may make the product more susceptible to rusting than an uncleaned product.Please be careful about the application location and storage environment.

Ler mais

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	RoHS compliant (10 substances)	2.5 ～ 8	Clean washing	10 ～ 60	-	Stainless Steel	Not Provided	Hex Socket

Preço regular (excluindo IVA):

7.35 €～

Data de envio regular:

7 dias úteis

KIPP
Shoulder screws with slotted flat head DIN 923 (K0704)
[Specifications]・Material: Steel・Surface finish body: black oxidised・Thread (M): 6, 8, 10[Features]・Suitable for moving connections due to their design・DIN 923
Ler mais
CAD:
2D
/3D
Detailed Shape Environmentally Friendly Screw Nominal (M) Properties / applications Length L (mm)(mm) Length L (inch)(inch) Material Surface Treatment Mounting Hole Shape
- - 6 ～ 10 - - - Steel - -
Preço regular (excluindo IVA):
2.02 €～
Data de envio regular:
4 dias úteis
Configurar

Reamer bolts / hexagonal / 10.9 / EN 14399-8

DESCONTO
Volume Discount

REYHER

Reamer bolts / hexagonal / 10.9 / EN 14399-8

Bolts for steel constructions; CE; DIN 18800; DIN 7999; EN 1090; EN 14399-8; HV-fitted bolts; Hexagon head screws; Steel bolts

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
-	-	16 ～ 30	-	45 ～ 180	-	Steel	-	Not Provided

Preço regular (excluindo IVA):

16.42 €～

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

KIPP
Shoulder screws with hexagon head similar to DIN 609 (K0706)
[Specifications]・Material: Steel・Surface finish body: black oxidised・Thread (M): 8-24・D1(mm): 9-25[Features]・For securing the position of workpieces・Ground shaft・DIN 609
Ler mais
CAD:
2D
/3D
Detailed Shape Environmentally Friendly Screw Nominal (M) Properties / applications Length L (mm)(mm) Length L (inch)(inch) Material Surface Treatment Mounting Hole Shape
- - 8 ～ 24 - - - Steel - -
Preço regular (excluindo IVA):
1.18 €～
Data de envio regular:
4 dias úteis
Configurar
NORELEM
Shoulder screws with slotted flat head DIN 923 (07530)
· Suitable for moving connections due to their design
Ler mais
Detailed Shape Environmentally Friendly Screw Nominal (M) Properties / applications Length L (mm)(mm) Length L (inch)(inch) Material Surface Treatment Mounting Hole Shape
- - 6 ～ 10 - - - Steel - Straight-Slot
Preço regular (excluindo IVA):
1.71 €～
Data de envio regular:
4 dias úteis
Configurar

Reamer bolts / hexagon socket / black oxided / 10.9 / SH

DESCONTO
Volume Discount

GOSHO WORKS

Reamer bolts / hexagon socket / black oxided / 10.9 / SH【1 a 25 unidades】

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	6 ～ 12	-	15 ～ 110	-	Steel	Black Oxide	Hex Socket

Preço regular (excluindo IVA):

3.12 €～

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Reamer bolts / hexagon socket / SBHH

Volume Discount

SUNCO

Reamer bolts / hexagon socket / SBHH【1 a 100 unidades】

[Detailed shape] Standard[Mounting hole shape] Hexagonal socket[Basic shape] Shoulder/stepped[Material] Steel[Surface treatment] None[Thread type] Metric coarse[Applications] Standard[Nominal thread (M)] 3/4/5/6/8/10/12/16/20[Pitch (mm)] 0.5/0.7/0.8/1/1.25/1.5/1.75/2/2.5

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	5 ～ 20	-	-	-	Steel	Not Provided	Hex Socket

Preço regular (excluindo IVA):

1.54 €～

Data de envio regular:

6 dias úteis

Reamer bolts / hexagon socket / A2-50 / inch thread UNF, UNC / IN51

Volume Discount

SAIMA CORPORATION

Reamer bolts / hexagon socket / A2-50 / inch thread UNF, UNC / IN51

Inch standard thread. For international sales etc.

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	-	-	-	1 ～ 7/8	Stainless Steel	Barrel, Passivated	Hex Socket

Preço regular (excluindo IVA):

25.46 €～

Data de envio regular:

8 dias úteis

HALDER
Reamer bolts / hexagon socket / tolerance k5 / 10.9
[Specifications]・Material: Heat-treated steel・d1: M12, M16[Features]・Heat-treated steel, tempered, quality 10.9
Ler mais
CAD:
3D
Detailed Shape Environmentally Friendly Screw Nominal (M) Properties / applications Length L (mm)(mm) Length L (inch)(inch) Material Surface Treatment Mounting Hole Shape
- - M12 ～ M16 - - - Steel - -
Preço regular (excluindo IVA):
13.83 €～
Data de envio regular:
4 dias úteis
Configurar

Locator Bolt (Standard Series) (BJ700)

IMAO CORPORATION

Locator Bolt (Standard Series) (BJ700)

Reamer bolt with f7 locator part tolerance.[Features]· Reamer bolt locator part has f7 tolerance.

Ler mais

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	12 ～ 16	-	45 ～ 75	-	Steel	Black Oxide	Hex Socket

Preço regular (excluindo IVA):

14.05 €～

Data de envio regular:

6 dias úteis

Flat head screws / slotted / steel / zinc plated / shank / DIN 923 /

DESCONTO
Volume Discount

REYHER

Flat head screws / slotted / steel / zinc plated / shank / DIN 923 /

slotted cheese head shoulder screws

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
-	-	3 ～ 10	-	0 ～ 25	-	Steel	-	With Cross/Straight Slot

Preço regular (excluindo IVA):

0.24 €～

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Reamer bolts / with female thread / hexagon socket / black oxided / PBA

DESCONTO
Volume Discount

OHKITA

Reamer bolts / with female thread / hexagon socket / black oxided / PBA

Screws for plastic molds.Designed to withstand repeated impacts in the direction of tension.Internal threading type.Material = SCM435; Hardness = HRC34 to 44; Surface Processing = Black Oxide / Temper Color

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	6 ～ 16	-	12 ～ 35	-	Steel	Black Oxide	Hex Socket

Preço regular (excluindo IVA):

6.12 €～

Preço regular (excluindo IVA):

Preço especial

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Reamer bolts / hexagonal / with nut, long version / DIN 7968

Volume Discount

REYHER

Reamer bolts / hexagonal / with nut, long version / DIN 7968

Bolts for steel constructions; CE; DIN 18800; EN 1090; Fitting bolts; Hexagon head fitting screws

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
-	-	12 ～ 24	-	35 ～ 140	-	Steel	-	Not Provided

Preço regular (excluindo IVA):

10.52 €～

Data de envio regular:

3 dias úteis

Locator Bolt (High-Precision Series) (BJ701)

Volume Discount

IMAO CORPORATION

Locator Bolt (High-Precision Series) (BJ701)

High accuracy reamer bolt with locator part tolerance of -0.013 - 0.005.

Ler mais

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	12 ～ 16	-	45 ～ 75	-	Steel	Black Oxide	Hex Socket

Preço regular (excluindo IVA):

16.03 €～

Data de envio regular:

6 dias úteis

Reamer bolts / hexagon socket / black oxided / SW-02

Volume Discount

IMAO CORPORATION

Reamer bolts / hexagon socket / black oxided / SW-02

Shoulder bolts for hooked washers SW for jigs. The black oxide coating serves as rust protection.

Ler mais

CAD:: 2D; /3D

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	6 ～ 8	-	15 ～ 20	-	-	Black Oxide	Hex Socket

Preço regular (excluindo IVA):

5.90 €～

Data de envio regular:

Item em stock: 1 dia útil

Alguns artigos podem ser enviados no próprio dia

Reamer bolts / hexagon socket / black oxided / STS-A

Volume Discount

OHKITA

Reamer bolts / hexagon socket / black oxided / STS-A

A 2-piece structure of bolt and sleeve.Unlikely to loosen due to sleeve spring effect.Material = SCM435; Hardness = HRC34 to 44; Surface Processing = Black Oxide / Temper Color

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	10 ～ 12	-	15 ～ 18	-	Steel	Black Oxide	Hex Socket

Preço regular (excluindo IVA):

2.72 €～

Data de envio regular:

6 dias úteis

Reamer bolts / with washer / hexagon socket / black oxided / STS-B

Volume Discount

OHKITA

Reamer bolts / with washer / hexagon socket / black oxided / STS-B

The 3-piece structure of bolt, sleeve and flange secures the seating surface to the object to be retained.Unlikely to loosen due to sleeve spring effect.[Material] Bolt = SCM435, Sleeve = STKM13AC, Flange = SK3-5[Hardness] HRC 34-44[Surface Processing] Black Oxide / Temper Color

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	14 ～ 20	-	22 ～ 36	-	Steel	Black Oxide	Hex Socket

Preço regular (excluindo IVA):

9.57 €～

Data de envio regular:

7 dias úteis

Reamer bolts / double socket / hexagon socket / PBC

Volume Discount

OHKITA

Reamer bolts / double socket / hexagon socket / PBC

Screws for plastic molds.Designed to withstand repeated impacts in the direction of tension.Material = SCM435; Hardness = HRC34 to 44; Surface Processing = Black Oxide / Temper Color

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
Standard	-	6 ～ 16	-	18 ～ 38	-	Steel	Black Oxide	Hex Socket

Preço regular (excluindo IVA):

3.97 €～

Data de envio regular:

7 dias úteis

Reamer bolts / hexagonal / with nut / DIN 7968

Volume Discount

REYHER

Reamer bolts / hexagonal / with nut / DIN 7968

Bolts for steel constructions; CE; DIN 18800; EN 1090; EN 15048; Fitting bolts; Hexagon head fitting screws

Ler mais

Detailed Shape	Environmentally Friendly	Screw Nominal (M)	Properties / applications	Length L (mm)(mm)	Length L (inch)(inch)	Material	Surface Treatment	Mounting Hole Shape
-	-	12 ～ 24	-	35 ～ 100	-	Steel	-	Not Provided

Preço regular (excluindo IVA):

4.86 €～

Data de envio regular:

3 dias úteis

O produto que procura não se encontra aqui?
