New Joint GWL □-□- T Series【1-10 Pieces Per Package】

Volume Discount

[Features]
· Flame retardant type with white body.
· Brass parts subject to electroless nickel plating

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Products homepage

Data to be displayed: 30; 45; 60

Part Number
GWL4-6-T-P70
GWL4-6-T-P80
GWL4-M5-T-P70
GWL4-M5-T-P80
GWL6-6-T-P70
GWL6-6-T-P80
GWL6-8-T-P80
GWL6-10-T-P80
GWL6-M5-T-P74
GWL6-M5-T-P80
GWL8-8-T-P80
GWL10-10-T-P80
GWL12-10-T-P80
GWL12-15-T-P80

Standard Unit Price	Number of pc(s). included in pkg.	Minimum order quantity	Volume Discount	Standard Shipping Days ?	Application	Seal	Compatible Tube Outer Diameter 1 (mm)	Pipe Connection Bore Dia.	Pipe connection port diameter 1 male screw	Option	Oil And Dust Resistant	Material Limit	Ozone Resistance Specifications
102.52 €	10 Pieces Per Package	1 pack	Available	9 Days	Clean circumstance	Standard (NBR)	4	R	1/8	NA	Preventing of Raising Dust	Without Material Limit	NA
126.05 €	10 Pieces Per Package	1 pack	Available	9 Days	Clean circumstance	Standard (NBR)	4	R	1/8	NA	No oil treatment	Without Material Limit	NA
93.46 €	10 Pieces Per Package	1 pack		9 Days	Clean circumstance	Standard (NBR)	4	M	M5	NA	Preventing of Raising Dust	Without Material Limit	NA
115.56 €	10 Pieces Per Package	1 pack	Available	9 Days	Clean circumstance	Standard (NBR)	4	M	M5	NA	No oil treatment	Without Material Limit	NA
112.29 €	10 Pieces Per Package	1 pack		8 Days	Clean circumstance	Standard (NBR)	6	R	1/8	NA	Preventing of Raising Dust	Without Material Limit	NA
137.83 €	10 Pieces Per Package	1 pack		9 Days	Clean circumstance	Standard (NBR)	6	R	1/8	NA	No oil treatment	Without Material Limit	NA
139.82 €	10 Pieces Per Package	1 pack		9 Days	Clean circumstance	Standard (NBR)	6	R	1/4	NA	No oil treatment	Without Material Limit	NA
112.48 €	10 Pieces Per Package	1 pack	Available	9 Days	Clean circumstance	Standard (NBR)	6	R	3/8	NA	No oil treatment	Without Material Limit	NA
86.23 €	10 Pieces Per Package	1 pack	Available	9 Days	Clean circumstance	Standard (NBR)	6	M	M5	NA	Preventing of Raising Dust	Not Acceptable for Copper, Silicon, Halogen-based	NA
106.50 €	10 Pieces Per Package	1 pack	Available	9 Days	Clean circumstance	Standard (NBR)	6	M	M5	NA	No oil treatment	Without Material Limit	NA
138.19 €	10 Pieces Per Package	1 pack	Available	9 Days	Clean circumstance	Standard (NBR)	8	R	1/4	NA	No oil treatment	Without Material Limit	NA
115.38 €	10 Pieces Per Package	1 pack		9 Days	Clean circumstance	Standard (NBR)	10	R	3/8	NA	No oil treatment	Without Material Limit	NA
130.18 €	10 Pieces Per Package	1 pack		9 Days	Clean circumstance	Standard (NBR)	12	R	3/8	NA	No oil treatment	Without Material Limit	NA
121.46 €	10 Pieces Per Package	1 pack		9 Days	Clean circumstance	Standard (NBR)	12	R	1/2	NA	No oil treatment	Without Material Limit	NA

Basic information

Type	Single-Action Coupling	Fitting Type	Screw Mount Direction	Applicable Fluids	Air
Main Body	Flame Retardant Resin(UL94 V-0 Equivalent)	Hammered Nipple	Brass (Electroless Nickel Plating)	Screw Mounting, Direction	Elbow
Elbows	Turn Elbow	Operating Temperature(°C)	-10::60

Configure

14Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.

The part number is completed.

Basic Attributes

Seal
- Standard (NBR)
- Ozone Resistant Rubber
Clear
Compatible Tube Outer Diameter 1(mm)
4

6

8

10

12
Clear
Pipe Connection Bore Dia.
- M
- R
Clear
Pipe connection port diameter 1 male screw
- 1/2
- 1/4
- 1/8
- 3/8
- M5
Clear
Option
- NA
- Non-Purple Specification
Clear
Oil And Dust Resistant
- No Clean Specifications
- No oil treatment
- Preventing of Raising Dust
Clear
Material Limit
- Not Acceptable for Copper, Silicon, Halogen-based
- Without Material Limit
Clear
Ozone Resistance Specifications
- NA
- Ozone Resistance
Clear
Type
- GWL□-□-T
Clear
Application
- Clean circumstance
Clear
