Proximity sensor, SIEN Series(Lista de números de peça: página 2)

Condições de filtragem

Housing material
Degree of protection
- IP65, IP67
- IP67
DC operating voltage range(V)
Type of mounting
- Clamped
- With lock nut
Cable length(m)
- 2.5
Material of cable sheath
- TPE-U(PUR)
Max. switching frequency(Hz)
- 700
- 1200
- 2000
- 3000
- 5000
Max. switching frequency DC(Hz)
- 3000
Size
Rated operating distance(mm)
- 0.8
- 1.5
- 2
- 2.5
- 4
- 5
- 8
- 10
- 15
Mounting type
- Flush
- Not flush
Electrical output
- NPN
- PNP
Tightening torque(Nm)
- 20
- 40
Switching output
- NPN
- PNP
Electrical connection
Repetition accuracy(mm)
- 0.04
- 0.25
- 0.4
- 0.5
- 0.75
Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- 4 - Particularly high corrosion stress
Dias de envio estimados
- Tudo
- Dentro de 3 dias úteis
- Dentro de 4 dias úteis
- Dentro de 7 dias úteis
- Dentro de 12 dias úteis

Proximity sensor, SIEN Series(Lista de números de peça: página 2)

Catálogo

Número da peça:

Indefinido. 87 candidatos encontrados.

Lista de números de peça
Informações detalhadas
Catálogo

Lista de números de peça

Número de itens

Número da peça

Relacionado

Housing material

Degree of protection

DC operating voltage range

(V)

Type of mounting

Cable length

(m)

Material of cable sheath

Max. switching frequency

(Hz)

Max. switching frequency DC

(Hz)

Size

Rated operating distance

(mm)

Mounting type

Electrical output

Tightening torque

(Nm)

Switching output

Electrical connection

Repetition accuracy

(mm)

Corrosion resistance class (CRC)

Weight

(g)

Manufacturer part #

Quantidade mínima de encomenda

Data sheet	Brass, PBTP, Nickel-plated	IP67	10-30	With lock nut	-	-	2000	-	M18x1	5	Flush	PNP	20	PNP	3-pin, M12x1, Plug	0.25	-	43	150423	1 unidades
Data sheet	Brass, PBTP, Nickel-plated	IP67	10-30	With lock nut	2.5	TPE-U(PUR)	2000	-	M18x1	5	Flush	PNP	20	PNP	3-wire, Cable	0.25	-	108	150418	1 unidades
Data sheet	Brass, PBTP, Nickel-plated	IP67	10-30	With lock nut	-	-	2000	-	M18x1	5	Flush	PNP	20	PNP	3-pin, M12x1, Plug	0.25	-	43	150419	1 unidades
Data sheet	Brass, PBTP, Nickel-plated	IP67	10-30	With lock nut	2.5	TPE-U(PUR)	2000	-	M18x1	8	Not flush	NPN	20	NPN	3-wire, Cable	0.4	-	105	150428	1 unidades
Data sheet	Brass, PBTP, Nickel-plated	IP67	10-30	With lock nut	-	-	2000	-	M18x1	8	Not flush	NPN	20	NPN	3-pin, M12x1, Plug	0.4	-	40	150429	1 unidades
Data sheet	Brass, PBTP, Nickel-plated	IP67	10-30	With lock nut	2.5	TPE-U(PUR)	2000	-	M18x1	8	Not flush	NPN	20	NPN	3-wire, Cable	0.4	-	105	150424	1 unidades
Data sheet	Brass, PBTP, Nickel-plated	IP67	10-30	With lock nut	-	-	2000	-	M18x1	8	Not flush	NPN	20	NPN	3-pin, M12x1, Plug	0.4	-	40	150425	1 unidades
Data sheet	Brass, PBTP, Nickel-plated	IP67	10-30	With lock nut	2.5	TPE-U(PUR)	2000	-	M18x1	8	Not flush	PNP	20	PNP	3-wire, Cable	0.4	-	105	150430	1 unidades
Data sheet	Brass, PBTP, Nickel-plated	IP67	10-30	With lock nut	-	-	2000	-	M18x1	8	Not flush	PNP	20	PNP	3-pin, M12x1, Plug	0.4	-	40	150431	1 unidades
Data sheet	Brass, PBTP, Nickel-plated	IP67	10-30	With lock nut	2.5	TPE-U(PUR)	2000	-	M18x1	8	Not flush	PNP	20	PNP	3-wire, Cable	0.4	-	105	150426	1 unidades
Data sheet	Brass, PBTP, Nickel-plated	IP67	10-30	With lock nut	-	-	2000	-	M18x1	8	Not flush	PNP	20	PNP	3-pin, M12x1, Plug	0.4	-	40	150427	1 unidades
Data sheet	Brass, PBTP, Chrome-plated	IP67	10-30	With lock nut	2.5	TPE-U(PUR)	1200	-	M30x1.5	10	Flush	NPN	40	NPN	3-wire, Cable	0.5	-	155	150436	1 unidades
Data sheet	Brass, PA, PBTP, Chrome-plated	IP67	10-30	With lock nut	-	-	1200	-	M30x1.5	10	Flush	NPN	40	NPN	3-pin, M12x1, Plug	0.5	-	100	150437	1 unidades
Data sheet	Brass, PBTP, Chrome-plated	IP67	10-30	With lock nut	2.5	TPE-U(PUR)	1200	-	M30x1.5	10	Flush	NPN	40	NPN	3-wire, Cable	0.5	-	155	150432	1 unidades
Data sheet	Brass, PA, PBTP, Chrome-plated	IP67	10-30	With lock nut	-	-	1200	-	M30x1.5	10	Flush	NPN	40	NPN	3-pin, M12x1, Plug	0.5	-	100	150433	1 unidades
Data sheet	Brass, PBTP, Chrome-plated	IP67	10-30	With lock nut	2.5	TPE-U(PUR)	1200	-	M30x1.5	10	Flush	PNP	40	PNP	3-wire, Cable	0.5	-	155	150438	1 unidades
Data sheet	Brass, PA, PBTP, Chrome-plated	IP67	10-30	With lock nut	-	-	1200	-	M30x1.5	10	Flush	PNP	40	PNP	3-pin, M12x1, Plug	0.5	-	100	150439	1 unidades
Data sheet	Brass, PBTP, Chrome-plated	IP67	10-30	With lock nut	2.5	TPE-U(PUR)	1200	-	M30x1.5	10	Flush	PNP	40	PNP	3-wire, Cable	0.5	-	155	150434	1 unidades
Data sheet	Brass, PA, PBTP, Chrome-plated	IP67	10-30	With lock nut	-	-	1200	-	M30x1.5	10	Flush	PNP	40	PNP	3-pin, M12x1, Plug	0.5	-	100	150435	1 unidades
Data sheet	Brass, PBTP, Chrome-plated	IP67	13-30	With lock nut	2.5	TPE-U(PUR)	700	-	M30x1.5	15	Not flush	NPN	40	NPN	3-pin, Cable	0.75	-	150	150444	1 unidades
Data sheet	Brass, PA, PBTP, Chrome-plated	IP67	14-30	With lock nut	-	-	700	-	M30x1.5	15	Not flush	NPN	40	NPN	3-pin, M12x1, Plug	0.75	-	100	150445	1 unidades
Data sheet	Brass, PBTP, Chrome-plated	IP67	10-30	With lock nut	2.5	TPE-U(PUR)	700	-	M30x1.5	15	Not flush	NPN	40	NPN	3-wire, Cable	0.75	-	150	150440	1 unidades
Data sheet	Brass, PA, PBTP, Chrome-plated	IP67	10-30	With lock nut	-	-	700	-	M30x1.5	15	Not flush	NPN	40	NPN	3-pin, M12x1, Plug	0.75	-	100	150441	1 unidades
Data sheet	Brass, PBTP, Chrome-plated	IP67	15-30	With lock nut	2.5	TPE-U(PUR)	700	-	M30x1.5	15	Not flush	PNP	40	PNP	3-pin, Cable	0.75	-	150	150446	1 unidades
Data sheet	Brass, PA, PBTP, Chrome-plated	IP67	16-30	With lock nut	-	-	700	-	M30x1.5	15	Not flush	PNP	40	PNP	3-pin, M12x1, Plug	0.75	-	100	150447	1 unidades
Data sheet	Brass, PBTP, Chrome-plated	IP67	11-30	With lock nut	2.5	TPE-U(PUR)	700	-	M30x1.5	15	Not flush	PNP	40	PNP	3-pin, Cable	0.75	-	150	150442	1 unidades
Data sheet	Brass, PA, PBTP, Chrome-plated	IP67	12-30	With lock nut	-	-	700	-	M30x1.5	15	Not flush	PNP	40	PNP	3-pin, M12x1, Plug	0.75	-	100	150443	1 unidades

Preço unitário (excluindo IVA)(Preço unitário incluindo IVA)	Data de envio standard

66.12 € ( 78.68 € )	4 dias úteis
66.12 € ( 78.68 € )	4 dias úteis
66.12 € ( 78.68 € )	4 dias úteis
69.31 € ( 82.48 € )	4 dias úteis
69.31 € ( 82.48 € )	4 dias úteis
69.31 € ( 82.48 € )	4 dias úteis
69.31 € ( 82.48 € )	4 dias úteis
66.12 € ( 78.68 € )	4 dias úteis
66.12 € ( 78.68 € )	4 dias úteis
66.12 € ( 78.68 € )	3 dias úteis
66.12 € ( 78.68 € )	4 dias úteis
72.48 € ( 86.25 € )	4 dias úteis
72.48 € ( 86.25 € )	4 dias úteis
72.48 € ( 86.25 € )	4 dias úteis
72.48 € ( 86.25 € )	4 dias úteis
69.31 € ( 82.48 € )	4 dias úteis
69.31 € ( 82.48 € )	4 dias úteis
69.31 € ( 82.48 € )	4 dias úteis
69.31 € ( 82.48 € )	4 dias úteis
72.48 € ( 86.25 € )	4 dias úteis
72.48 € ( 86.25 € )	7 dias úteis
72.48 € ( 86.25 € )	4 dias úteis
72.48 € ( 86.25 € )	4 dias úteis
69.31 € ( 82.48 € )	4 dias úteis
69.31 € ( 82.48 € )	12 dias úteis
69.31 € ( 82.48 € )	4 dias úteis
69.31 € ( 82.48 € )	4 dias úteis

Informações detalhadas

Informações básicas

Informações básicas

[Specifications]
・Degree of protection: IP65, IP67 / IP67
・Corrosion resistance class (CRC): 2 - Moderate corrosion stress, 4 - Particularly high corrosion stress
・Type of mounting: Clamped, With lock nut

[Features]
・Standard switching distance
・For DC voltage
・Round design
